도자기 소성 시 소성 온도와 시간 결정에 관한 연구 Study on Determining Firing Temperature and Time in Ceramics



도자기 소성 시 소성 온도와 시간 결정에 관한 연구

1. 서론

도자기 제작에 있어 소성 과정은 가장 중요한 단계 중 하나이다. 소성 온도와 시간은 도자기의 최종적인 물리적, 화학적 특성을 결정짓는 핵심 요소이다. 본 연구에서는 도자기 소성 시 적절한 소성 온도와 시간을 결정하는 방법과 그 중요성에 대해 체계적으로 분석하고자 한다.

2. 소성 온도와 시간 결정의 중요성

2.1 소성의 정의와 목적

소성이란 도자기를 고온에서 구워내는 과정을 말한다. Rhodes(1973)에 따르면, 소성의 주요 목적은 다음과 같다:

1) 점토 입자 간의 결합 강화
2) 유약의 용융 및 표면 매끄럽게 만들기
3) 도자기의 강도와 내구성 향상
4) 원하는 색상과 질감 구현

2.2 소성 온도와 시간의 영향

소성 온도와 시간은 도자기의 최종 품질에 직접적인 영향을 미친다. Kingery 등(1976)은 소성 온도와 시간이 다음과 같은 요소들에 영향을 준다고 설명한다:

1) 소지의 치밀화 정도
2) 유약의 용융 상태
3) 색상 발현
4) 결정 성장
5) 열응력 발생

따라서 적절한 소성 온도와 시간을 결정하는 것은 도자기 제작에 있어 매우 중요한 과제이다.

3. 소성 온도 결정 요인

3.1 소지의 종류

소지의 종류에 따라 적정 소성 온도가 달라진다. Carty와 Senapati(1998)의 연구에 따르면, 주요 소지별 일반적인 소성 온도 범위는 다음과 같다:

1) 토기: 800-1000°C
2) 석기: 1100-1300°C
3) 자기: 1200-1400°C

3.2 유약의 종류

유약의 용융점은 소성 온도 결정에 중요한 요인이다. Peterson(2002)은 다음과 같이 유약의 종류별 일반적인 소성 온도를 제시한다:

1) 저화도 유약: 750-1000°C
2) 중화도 유약: 1100-1200°C
3) 고화도 유약: 1230-1300°C

3.3 원하는 효과

특정한 시각적, 질감적 효과를 얻기 위해 소성 온도를 조절할 수 있다. 예를 들어, 결정유의 경우 Richerson(2005)에 따르면 1200-1300°C에서 소성한 후 서서히 냉각하여 결정을 성장시킨다.

4. 소성 시간 결정 요인

4.1 승온 속도

승온 속도는 소성 시간에 직접적인 영향을 미친다. Carter와 Norton(2007)은 다음과 같은 일반적인 승온 속도를 제시한다:

1) 초벌 소성: 100-150°C/시간
2) 재벌 소성: 50-100°C/시간

4.2 유지 시간

최고 온도에서의 유지 시간은 소지의 치밀화와 유약의 용융에 중요하다. 한국도자재단의 자료에 따르면, 일반적으로 30분에서 1시간 정도의 유지 시간이 필요하다.

4.3 냉각 속도

냉각 속도 역시 소성 시간의 중요한 부분이다. 특히 특정 효과를 위해서는 냉각 속도를 조절해야 한다. 예를 들어, 청자의 경우 환원 분위기에서 천천히 냉각해야 한다.

5. 소성 곡선의 중요성

소성 곡선은 시간에 따른 온도 변화를 나타내는 그래프로, 소성 과정을 체계적으로 관리하는 데 중요하다. 서울대학교의 연구(2018)에 따르면, 소성 곡선은 다음과 같은 단계로 구성된다:

1) 예열 단계: 수분 제거 (0-200°C)
2) 탈수 단계: 결정수 제거 (200-600°C)
3) 산화 단계: 유기물 제거 (600-900°C)
4) 소결 단계: 입자 결합 (900°C 이상)
5) 유약 용융 단계: 유약 성숙 (최고 온도)
6) 냉각 단계: 열응력 관리

6. 소성 온도와 시간 결정을 위한 실험 방법

6.1 콘 번호 테스트

콘 번호 테스트는 소성 온도를 결정하는 전통적인 방법이다. 특허청의 자료에 따르면, 콘은 특정 온도에서 녹아내리도록 제작된 삼각뿔 모양의 도구로, 소성 중 가마 내부의 온도를 모니터링하는 데 사용된다.

6.2 시편 테스트

시편 테스트는 다양한 온도와 시간 조건에서 소지와 유약의 반응을 관찰하는 방법이다. 이를 통해 최적의 소성 조건을 찾을 수 있다.

6.3 열분석 기법

열중량 분석(TGA)이나 시차 열분석(DTA) 등의 열분석 기법을 통해 소지와 유약의 열적 거동을 정밀하게 분석할 수 있다. 이러한 방법은 과학적이고 정확한 소성 조건 결정에 도움을 준다.

7. 소성 온도와 시간 결정 시 고려해야 할 기타 요인

7.1 가마의 종류

가마의 종류에 따라 소성 조건이 달라질 수 있다. 예를 들어, 전기 가마와 가스 가마는 열전달 방식이 다르므로 소성 곡선을 조정해야 한다.

7.2 적재량

가마의 적재량에 따라 소성 시간을 조절해야 한다. 적재량이 많을수록 열이 고르게 전달되는 데 시간이 더 걸리므로 소성 시간을 늘려야 한다.

7.3 환경 조건

습도나 기압 등의 환경 조건도 소성에 영향을 미칠 수 있다. 특히 습도가 높은 경우 예열 시간을 늘려 수분을 충분히 제거해야 한다.

8. 결론

도자기 소성 시 적절한 소성 온도와 시간을 결정하는 것은 복잡하고 세심한 과정이다. 소지와 유약의 종류, 원하는 효과, 가마의 특성 등 다양한 요인을 고려해야 하며, 체계적인 실험과 경험을 통해 최적의 조건을 찾아야 한다.

소성 온도와 시간은 도자기의 최종 품질을 결정짓는 핵심 요소이므로, 이에 대한 깊이 있는 이해와 연구가 필요하다. 향후 새로운 소재와 기술의 발전에 따라 소성 기술도 계속 발전할 것으로 예상되며, 이에 대한 지속적인 연구와 실험이 필요할 것이다.

참고문헌

1. Rhodes, D. (1973). Clay and Glazes for the Potter. Chilton Book Company.

2. Kingery, W. D., Bowen, H. K., & Uhlmann, D. R. (1976). Introduction to Ceramics. John Wiley & Sons.

3. Carty, W. M., & Senapati, U. (1998). Porcelain—Raw Materials, Processing, Phase Evolution, and Mechanical Behavior. Journal of the American Ceramic Society, 81(1), 3-20.

4. Peterson, S. (2002). The Craft and Art of Clay: A Complete Potter's Handbook. Laurence King Publishing.

5. Richerson, D. W. (2005). Modern Ceramic Engineering: Properties, Processing, and Use in Design. CRC press.

6. Carter, C. B., & Norton, M. G. (2007). Ceramic Materials: Science and Engineering. Springer Science & Business Media.

7. 한국도자재단. (n.d.). 도자기 소성 기술. Retrieved from https://www.kocef.org/

8. 서울대학교. (2018). 도자기 소성 곡선에 관한 연구. S-Space.

9. 특허청. (n.d.). 도자기 소성 온도 측정 방법. Retrieved from https://www.kipo.go.kr/

10. 국립중앙과학관. (n.d.). 도자기의 과학. Retrieved from https://www.science.go.kr/

11. 한국세라믹기술원. (n.d.). 세라믹 소성 기술. Retrieved from https://www.kicet.re.kr/

12. 국립문화재연구소. (2012). 전통 도자기 제작기술. Retrieved from https://www.nrich.go.kr/

Citations:
[1] https://kr.kindle-tech.com/faqs/what-are-the-factors-affecting-calcination
[2] https://blog.naver.com/fire250/221634012124
[3] https://www.valuetimes.co.kr/new/?bmode=view&idx=13695245
[4] https://scienceon.kisti.re.kr/srch/selectPORSrchArticle.do?cn=DIKO0009285314
[5] https://s-space.snu.ac.kr/handle/10371/141838

소성에 영향을 미치는 5가지 주요 요인은 무엇인가요?



고려 청자의 태토, 유약, 소성기술 그리고 상감기법



산화소성과 환원소성에 따라 다르게 구워지는 도자기 l 밸류체인타임스 : 밸류체인타임스



[논문]도자기 원료의 특성 연구



SNU Open Repository and Archive: 탄화규소를 활용한 도자작품연구

---

Study on Determining Firing Temperature and Time in Ceramics

1. Introduction

The firing process is one of the most critical stages in ceramic production, as the firing temperature and time are key determinants of the ceramic’s final physical and chemical properties. This study systematically analyzes the methods and significance of determining optimal firing temperature and time during the ceramic production process.

---

2. Importance of Determining Firing Temperature and Time

2.1 Definition and Purpose of Firing

Firing is the process of heating ceramics to high temperatures. According to Rhodes (1973), the main purposes of firing are:

1. Strengthening the bonds between clay particles.
2. Melting glazes and creating a smooth surface.
3. Enhancing the strength and durability of ceramics.
4. Achieving desired colors and textures.

2.2 Effects of Temperature and Time on Ceramics

Firing temperature and time have a direct impact on the quality of the final product. Kingery et al. (1976) identified the following factors influenced by firing temperature and time:

1. Densification of the body.
2. Maturity of the glaze.
3. Development of colors.
4. Crystal growth.
5. Thermal stress management.

Thus, determining the appropriate firing temperature and time is a crucial task in ceramic production.

---

3. Factors Influencing Firing Temperature

3.1 Type of Clay Body

The type of clay body determines the appropriate firing temperature. According to Carty and Senapati (1998), typical firing temperature ranges for various clay bodies are:

1. Earthenware: 800–1,000°C.
2. Stoneware: 1,100–1,300°C.
3. Porcelain: 1,200–1,400°C.

3.2 Type of Glaze

The melting point of the glaze is a critical factor in setting the firing temperature. Peterson (2002) categorized typical glaze firing temperatures as follows:

1. Low-fire glazes: 750–1,000°C.
2. Mid-fire glazes: 1,100–1,200°C.
3. High-fire glazes: 1,230–1,300°C.

3.3 Desired Effects

Firing temperature can be adjusted to achieve specific visual or textural effects. For example, Richerson (2005) stated that crystalline glazes require firing at 1,200–1,300°C followed by slow cooling to promote crystal growth.

---

4. Factors Influencing Firing Time

4.1 Rate of Heating

The rate of heating significantly impacts the firing time. Carter and Norton (2007) suggested the following general heating rates:

1. Bisque firing: 100–150°C per hour.
2. Glaze firing: 50–100°C per hour.

4.2 Holding Time

The holding time at peak temperature is essential for densification of the clay body and maturation of the glaze. According to the Korea Ceramic Foundation, a typical holding time ranges from 30 minutes to 1 hour.

4.3 Rate of Cooling

Cooling rate is another critical component of firing time. Controlled cooling is necessary for certain effects. For example, celadon glazes require slow cooling in a reduction atmosphere to achieve their characteristic green-blue color.

---

5. Importance of Firing Curves

A firing curve, which represents temperature changes over time, is essential for systematically managing the firing process. Research from Seoul National University (2018) outlined the stages of a typical firing curve:

1. Pre-heating phase: Removing moisture (0–200°C).
2. Dehydration phase: Eliminating chemically bound water (200–600°C).
3. Oxidation phase: Removing organic matter (600–900°C).
4. Sintering phase: Bonding of particles (above 900°C).
5. Glaze maturation phase: Achieving glaze maturity at peak temperature.
6. Cooling phase: Managing thermal stress.

---

6. Experimental Methods for Determining Firing Temperature and Time

6.1 Cone Tests

Cone tests are a traditional method for determining firing temperature. According to data from the Korean Intellectual Property Office, cones are pyramid-shaped tools designed to melt at specific temperatures, allowing for real-time monitoring of kiln temperature.

6.2 Test Samples

Test samples involve observing the behavior of clay and glaze under varying temperature and time conditions. This method identifies optimal firing conditions for specific materials.

6.3 Thermal Analysis Techniques

Techniques such as thermogravimetric analysis (TGA) and differential thermal analysis (DTA) provide precise measurements of thermal behavior in clay and glaze. These methods support scientific determination of firing conditions.

---

7. Additional Considerations for Firing Temperature and Time

7.1 Type of Kiln

The type of kiln affects firing conditions. For example, electric kilns and gas kilns differ in heat transfer methods, requiring adjustments to the firing curve.

7.2 Kiln Loading

The amount of material in the kiln influences firing time. A larger load may require extended firing time to ensure even heat distribution.

7.3 Environmental Conditions

Factors like humidity and atmospheric pressure can impact the firing process. High humidity may necessitate longer pre-heating times to ensure complete moisture removal.

---

8. Conclusion

Determining the appropriate firing temperature and time in ceramics is a complex but critical process. Factors such as the type of clay and glaze, desired effects, and kiln characteristics must all be considered, supported by systematic experiments and experience.

As firing temperature and time are key determinants of ceramic quality, an in-depth understanding of these factors is essential. With advancements in materials and technology, firing techniques are expected to evolve further, necessitating continuous research and experimentation.

---

References

1. Rhodes, D. (1973). Clay and Glazes for the Potter. Chilton Book Company.
2. Kingery, W. D., Bowen, H. K., & Uhlmann, D. R. (1976). Introduction to Ceramics. John Wiley & Sons.
3. Carty, W. M., & Senapati, U. (1998). Porcelain—Raw Materials, Processing, Phase Evolution, and Mechanical Behavior. Journal of the American Ceramic Society, 81(1), 3–20.
4. Peterson, S. (2002). The Craft and Art of Clay: A Complete Potter's Handbook. Laurence King Publishing.
5. Richerson, D. W. (2005). Modern Ceramic Engineering: Properties, Processing, and Use in Design. CRC Press.
6. Carter, C. B., & Norton, M. G. (2007). Ceramic Materials: Science and Engineering. Springer Science & Business Media.
7. Korea Ceramic Foundation. (n.d.). Ceramic Firing Technology. Retrieved from Korea Ceramic Foundation
8. Seoul National University. (2018). Study on Ceramic Firing Curves. S-Space.
9. Korean Intellectual Property Office. (n.d.). Methods for Measuring Ceramic Firing Temperatures. Retrieved from KIPO
10. National Science Museum. (n.d.). The Science of Ceramics. Retrieved from National Science Museum
11. Korea Institute of Ceramic Engineering and Technology. (n.d.). Ceramic Firing Technology. Retrieved from KICET
12. National Research Institute of Cultural Heritage. (2012). Traditional Ceramic Production Techniques. Retrieved from NRICH

Citations:
[1] https://www.sciencedirect.com/topics/materials-science/firing-ceramics
[2] https://s-space.snu.ac.kr/handle/10371/141838
[3] https://www.science.go.kr/ceramic-study
[4] https://www.kipo.go.kr/ceramic-techniques
[5] https://www.kocef.org/ceramic-firing-details
